  • Precise RF Emitter Location Finding

    HFDF is the tactical High-Frequency Direction Finding and Monitoring System. It provides Electronic Support Measures (ESM) for communication systems in HF Band. HFDF is an ideal solution for the «tactical combat units» in challenging operational environments (typically mountaneous). The system can be operated locally or remotely via an ethernet interface with full functionality. The core equipment of the system is an eight channel narrowband or wideband HF tuner subsystem. The system provides DF and monitoring against targets communicating over both ground-wave and sky-wave.

    HFDF

    HF Direction Finding, Geolocation and Monitoring System (HFDF)

    HFDF is the tactical High-Frequency Direction Finding and Monitoring System. It provides Electronic Support Measures (ESM) for communication systems in HF Band.

    Capabilities:

    • HF Frequency Coverage
    • Superb performance against both Ground-Wave and Sky-Wave HF signals
    • Several Antenna Array Geometry Alternatives
    • Full Digital Receiving Architecture
    • Recording and Offline Analysis Software
    • Remote Control via Ethernet Interface
    • Multichannel DF Receiver
    • User-Friendly GUIs
    • Easy Installation
    • Demodulation of analog and digital modulations
    • Protocol decoding and analysis tools (a full list of modulations and protocols can be provided upon request)
    HFDF

    Technical Specifications



    Frequency Coverage: 2-30 MHz
    Receiver Architecture:
    Wideband & Narrowband
    Coverage:
    360° Azimuth, 0°-85° Elevation
    DF Accuracy:
    <2° RMS
    Weight:
    < 50 kg
    Operational Temperature:
    -10°C/+50°C
